MCV-28 – 11/8 COPPER MAGNETIC CHECK VALVE FOR REFRIGERATION CIRCUIT
Description:
A 11/8 copper magnetic check valve for refrigeration systems is a component designed to prevent the return flow of refrigerant in the system, ensuring one-way flow.
General Features:
Magnetic valve seat, teflon diaphragm. 11/8 copper connection
Near-zero internal leakage rate
Compatible with all CFC, HCFC, and HFC refrigerants and oils
Operating temperature range: -40°C~+130°C
Minimal flow resistance, high flow capacity
Compact size, lightweight, installable in any position
Mesh inside valve body: not just a check valve, but also a filter
Specifications:
Material: Copper body, ideal for refrigeration applications
Size: 11/8 connections (approx. 28.58 mm diameter)
Magnetic operation: Uses a magnetic mechanism for better sealing and flow response
Application: Suitable for commercial refrigeration and air conditioning systems
Compatibility: Works with refrigerants such as R22, R134a, R404A, R407C, R410A, R507
Installation: Brazed directly onto copper piping, ensuring secure and long-lasting connection
Data:
Connection: 11/8
Safety operating pressure (Kpa): 4100
Outer diameter (OD): 54 mm
Length: 213 mm
Mesh count: 40
Liquid capacity: 188.52 kW
Product code: MCV-28
