Manufacturer: ILME
Connector type: square
Connector type: female
Connector series: CK/MK
Number of pins: 5
Type of pin configuration: 4+PE
Case: size 21.21
Rated current: 10A
Rated voltage: 250V
Wire cross section: 0.75…2.5mm2
Mechanical durability: 500cycles
Contact plating: silver plated
Contact material: brass
Max. contact resistance:: 1mO
Test voltage: 4kV
Operating temperature: -40…100°C
Mechanical mounting: for cable
Electrical mounting: screw terminal
Conform to the norm: CE, CSA, DIN VDE 0627, IEC 61984, UL
