Descrizione
Specifiche
|
Input Port |
HDMI x 1, USB-A x 2 |
|
Output Port |
HDMI x 1, USB-A x 1 |
|
Extensions Distance |
120m (396 feet) for both HDMI and USB signal. |
|
USB transmission rate |
480Mbps |
|
USB Standard |
USB 2.0 |
|
Vertical Frequency Range |
50/60Hz |
|
Interlaced Resolutions(50&60Hz) |
480i,576i,1080i |
|
Progressive Resolutions(50&60Hz) |
480p,576p,720p,1080p |
|
Limited Warranty |
1 Year Parts and Labor |
|
Operating Temperature |
0 to 50 |
|
Storage Humidity |
5% to 90% RH non-condensation |
|
Power Supply |
DC 5V 1A x 2pcs |
|
Power Consumption (Max) |
TX: 2W, RX: 2W |
|
Extender Unit Cert |
FCC, CE, RoHS |
|
Power Supply Cert |
FCC, CE, RoHS |
|
Dimension(LxWxH) |
TX/RX: 110 x 90 x 27mm |
|
Net Weight |
TX:160g, RX:170g |
|
Material |
Metal |
|
User Manual |
English Version |
