Descrizione
Omron G5V-2-H1 is a miniature signal relay with high coil sensitivity (High-sensitivity) designed for switching low to medium power in control and measurement circuits. Thanks to the DPDT (2c) configuration, it allows simultaneous switching of two independent contact branches in a compact design.
Technical specifications
Model series: G5V-2
Version: G5V-2-H1
Nominal coil voltage: 24 V DC
Rated coil current: 8.33 mA
Coil resistance: 2,880
Coil consumption: approximately 200 mW
Contacts: DPDT (2c)
Contact type: bifurcated crossbar
Contact material: Ag + Au-alloy
Rated load (resistive): 0.5 A at 125 VAC; 1 A at 24 VDC
Rated continuous current (rated carry current): 2 A
Maximum switching voltage: 125 VAC, 125 VDC
Maximum switching current: 1 A
Contact resistance: max. 100 m
Switching time: max. 7 ms
Opening time: max. 3 ms
Insulation resistance: min. 1,000 M (at 500 VDC)
Dielectric strength between coil and contacts: 1,000 VAC, 50/60 Hz for 1 min
Dielectric strength between contacts of the same polarity (High-sensitivity): 500 VAC, 50/60 Hz for 1 min
Dielectric strength between contacts of different polarity: 1,000 VAC, 50/60 Hz for 1 min
Impulse withstand voltage: 1,500 V (10 x 160 µs)
Ambient operating temperature: -25 °C to +70 °C (without icing and condensation)
Operating ambient humidity: 5% to 85%
Weight: approximately 5 g
Functions and features
High-sensitivity version with reduced coil consumption for energy-efficient control circuits
DPDT (2c) configuration for switching two signal branches
Contacts with bifurcated crossbar design for reliable signal switching
Defined switching times suitable for fast control applications
High insulation resistance and proven dielectric parameters for safe circuit separation
Ideal for
Control and automation modules
Measuring instruments and test fixtures
Signal switching in industrial and laboratory electronics
Interface between logic and power section with requirement for galvanic isolation
Package contents
1x Omron G5V-2-H1 relay, 24 V DC coil
Why choose this product?
Proven range of signal relays with defined electrical and insulation parameters
High-sensitivity option for applications with limited coil power consumption
DPDT contacts allow flexible wiring (switching of two branches)
Contact and insulation parameters suitable for a wide range of control applications
Installation and operating instructions
When designing, consider the type of load (resistive/inductive) and, if necessary, use interference suppression elements to limit surge voltage during expansion.
Observe the 24 V DC coil ratings and ensure a stable power supply including correct polarity.
For long-term reliability, verify the switching currents and voltages under real operating conditions.
Safety notice
The relay can switch voltages up to 125 VAC / 125 VDC; working with hazardous voltages requires professional qualifications and compliance with relevant standards.
Before handling, disconnect the device from the power supply and verify that there is no voltage.
