Descrizione
Sealed/Unsealed: unsealed
Male/Female: F
Tab Size_ 6.0mm(250)
Mating parts: 8230-4050 (HD series/250 type connector/DS series/HM series)
Applicable wire size : 0.3mm2
Cable overall diameter (mm): 1.4-1.9
Materials: Brass
Surface treatment: Anti-Corrsion treatment
Thickness (mm): 0.32
Contact resistance: Initial 3mOhm Max.
after durability tests 6mOhm Max.
Leak current: 1mA Max.
Insulation resistance: 100MOhm Min.
