Descrizione
The SLDH-12VDC-1C relay from Songle is a high-performance automotive relay designed to switch loads up to 80A at 14VDC. Its robust design, wide temperature range and high reliability make it ideal for use in automotive, power supply and industrial systems. The relay is equipped with a changeover contact (1C) that allows for universal wiring.
Technical specifications
Model: SLDH-12VDC-1C
Contact type: 1× changeover (SPDT, 5pin)
Coil voltage: 12 V DC
Rated contact current: NO: 80 A / NC: 60 A (14 V DC)
Contact material: AgCdO, AgSnO, AgNi
Maximum switching voltage: 30 V DC / 250 V AC
Maximum switching current: 70 A (14 V DC)
Maximum switching power: 980 W
Coil resistance: 90 ±10% (at 20 °C)
Nominal coil current: 133 mA
Nominal coil power consumption: approx. 1.6 W
Pull-up voltage: 8.4 V DC
Dropout voltage: 1.2 V DC
Insulation resistance: 100 M (at 500 V DC)
Dielectric strength: 500 V AC / 1 minute
Switching time: 10 ms
Opening time: 10 ms
Operating temperature: 40 °C to +125 °C
Vibration resistance: 10-55 Hz, 1.5 mm
Electrical life: 1×10 cycles (at 14 V DC, 40 A)
Mechanical life: 1×10 cycles
Dimensions: 28.5 × 28.5 × 25.3 mm
Weight: approximately 30g
Certification: RoHS compliant
Functions and features
High current capacity up to 80 A (NO)
Robust construction resistant to heat and vibration
Universal 5-pin connection NO/NC contact
Fast response with short switching time
High mechanical and electrical durability
Suitable for installation in automotive and industrial systems
Ideal for
Automotive systems lights, pumps, fans, heating
Power and switching modules
Control units and automation applications
High-current DC circuits
Package contents
1× relay SLDH-12VDC-1C
Why choose this product?
High switching current up to 80 A ideal for automotive applications
Wide operating temperature range up to +125 °C
Reliable performance with long service life
Quality and precise workmanship from the manufacturer Songle Relay
